Ground modular terminal blockJSLKG 3

JSLKG 3

DownloadPDF

Basic Information

Category	Ground modular terminal block
Model	JSLKG 3
Thickness	5.2mm
Width	42.5mm

Related products

Jointlean provides samples for user experience

JSLKG 3

Terminal size
Thickness/width/Endplate thickness[mm]	5.2/42.5
Height(TS 35:7.5/TS 35:15/TS 32)[mm]	47/54.5/52
Technical data in accordance with IEC/DIN and VDE
Cross section(Rigid/flexible)[mm2]	0.2-4/0.2-2.5
Rated pulse withstand voltage/contamination class[kV]/-	8/3
Overvoltage level/Insulation materialgroup	III/I
Capacity connection
Flexible conductor with bare tubular /tubular pre-insulated tip[mm2]	0.25-2.5/0.25-1.5
Multiple connection（2 conductors with same cross section）
Rigid/flexible conductor[mm2]	0.2-1.5/0.2-1.5
Flexible conductor with bare tubular tip[mm2]	0.25-1.5
Flexible conductor with tubular pre-insulated TWIN ferrule[mm2]	0.5-1.5
Stripping length[mm]	7
Internal cylindrical gauge(IEC 60 947-1)	A3
Wiring screw：screw type/Torque[Nm]	M3/0.6-0.8
Central fixed screw：screw type/Torque[Nm]	M3/0.6-0.8
Insulation material	PA
Inflammability class in acc.with UL 94	V0
Approva ldata(UL/CUL and CSA)
conductor sizes UL:AWG	30-12
CSA/CUL:AWG	28-12
